PHYS 3260 Lecture Notes

Mathematical Methods in the Physical Sciences

Erfan Saydanzad · Kennesaw State University
Chapter 0 Math Review for Calculus-Based Physics Chapter 1 Infinite Series and Power Series Chapter 2 Complex Numbers Chapter 3 Linear Algebra Chapter 4 Partial Differentiation Chapter 5 Multiple Integrals; Applications of Integration Chapter 6 Vector Analysis Chapter 7 Fourier Series and Transforms Chapter 8 Ordinary Differential Equations Chapter 9 Series Solutions of Ordinary Differential Equations (Chapter 12) Chapter 10 Partial Differential Equations (Chapter 13)

Why Mathematics Is Important for Learning Physics

Mathematics is the working language of physics. From Newton's laws to Schrödinger's equation, every major physical theory is written in mathematical form, and a physical idea is only as precise as the mathematics used to express it. The methods in these notes are not a detour on the way to physics; they are part of the way physics is actually done.

Instead of meeting these methods one at a time and wondering where each one leads, it is more useful to see the destination first. The three areas below will already be familiar. Each raises a concrete mathematical problem, and each problem is addressed by chapters in these notes. The same core tools appear repeatedly: series for approximation, linear algebra for coupled systems, and differential equations for change.

The core courses of a physics degree (classical mechanics, electromagnetism, quantum mechanics, thermodynamics and statistical mechanics, and special relativity) are each built on equations, and the central ones are differential equations. Newton's second law is an ordinary differential equation (ODE): its unknown, the position, depends on a single variable, the time. Maxwell's equations are partial differential equations (PDEs): the fields depend on x , y , z and t at once. Schrödinger's equation is an ODE in one dimension and a PDE in three. For each area below we therefore ask the same questions: what do we typically do there, what is known and what is unknown, and which mathematics finds the unknown.

1. Classical Mechanics

Video Lecture 1, Part 1: The Language of Physics (0:00)

At its foundation, mechanics begins with Newton's second law, which is a second-order ordinary differential equation:

F → net = m a → = m d v → d t = m d 2 r → d t 2 , v → = d r → d t .

Given a force law, solving for the motion is the central task of the subject. We know the mass m , the net force F → net , the initial position r → 0 and the initial velocity v → 0 ; we want the position r → ( t ) and the velocity v → ( t ) at every later time. For a constant force, such as gravity near the ground, the equation is easy to solve; for most forces it is hard, and the methods of these notes are what make progress possible.

Fig1

Where this is developed:

  • Ordinary Differential Equations (Ch. 8): first- and second-order equations

  • Linear Algebra (Ch. 3): systems of equations, eigenvalue problems, normal modes

  • Infinite Series and Power Series (Ch. 1): approximating motion when no exact solution exists

Applications: oscillators, planetary motion, variational formulations

2. Electromagnetism

Video Lecture 1, Part 2: Electromagnetism (6:33)

Maxwell's equations describe how electric and magnetic fields behave in matter:

∇ → ⋅ D → = ρ f , ∇ → ⋅ B → = 0 ∇ → × E → = − ∂ B → ∂ t , ∇ → × H → = J → f + ∂ D → ∂ t

Electric fields come from charge, described by the free charge density ρ f ( r ′ → , t ) at a source point r ′ → , and from changing magnetic fields. When charges move, they form a current, with free current density J → f ( r ′ → , t ) , and a current generates a magnetic field. Maxwell's equations connect these sources to the fields. Given the sources, and how D → is related to E → and H → to B → in the material, we want the fields E → ( r → , t ) and B → ( r → , t ) at every field point r → . Each is a function of four variables, E → ( r → , t ) = E → ( x , y , z , t ) , so the equations that govern them are partial differential equations.

Fig2

They are written in the language of vector calculus, so learning that language is essential for reading, interpreting, and applying them. One of the first and most striking predictions of these equations is light itself. In empty space, Maxwell's equations combine into a wave equation, and the waves it describes travel at the speed

c = 1 μ 0 ε 0 .

When this speed is computed from the measured constants μ 0 and ε 0 , it equals the measured speed of light: light is an electromagnetic wave.

A light wave travelling in the x direction. The electric field (red) and the magnetic field (blue) oscillate in step, at right angles to each other and to the direction of travel.
A light wave travelling in the x direction. The electric field (red) and the magnetic field (blue) oscillate in step, at right angles to each other and to the direction of travel.

Where this is developed:

  • Vector Analysis (Ch. 6): gradient, divergence, curl; Gauss's and Stokes's theorems

  • Partial Differential Equations (Ch. 10): Laplace's, Poisson's, and wave equations

  • Fourier Series and Transforms (Ch. 7): solving boundary value problems for fields

  • Multiple Integrals (Ch. 5): charge and current distributions in space

Applications: fields in dielectrics, waveguides, and AC circuits

3. Quantum Mechanics

Video Lecture 1, Part 3: Quantum Mechanics (14:17)

In quantum mechanics, a particle is described by a wavefunction that evolves according to the Schrödinger equation:

i ℏ ∂ ψ ∂ t = − ℏ 2 2 m ∇ 2 ψ + V ψ .

This equation is complex-valued and, once again, a partial differential equation. Two recurring threads of these notes meet here directly. For a state of definite energy E , the wavefunction obeys the time-independent Schrödinger equation,

− ℏ 2 2 m ∇ 2 ψ ( r → ) + V ( r → ) ψ ( r → ) = E ψ ( r → ) .

We know the potential V ( r → ) (for the hydrogen atom, V ( r ) = − e 2 / ( 4 π ε 0 r ) ) and the mass m ; we want the wavefunction ψ ( r → ) and the energy E . Only certain energies satisfy the equation: they are the eigenvalues of the energy operator. In one dimension the equation is an ordinary differential equation; in three dimensions, separating the variables turns it into ordinary differential equations that are solved with series.

Fig3

Where this is developed:

  • Complex Numbers (Ch. 2): Euler's formula, complex amplitudes

  • Linear Algebra (Ch. 3): operators, eigenvalues, Hilbert space

  • Fourier Series and Transforms (Ch. 7): analysing wavefunctions in different bases

  • Partial Differential Equations (Ch. 10): time-dependent and time-independent Schrödinger equations

  • Series Solutions (Ch. 9): special functions such as Legendre and Bessel

Applications: atomic structure, tunnelling, and the harmonic oscillator

Video Lecture 1, Part 4: The Toolkit and the Road Ahead (19:09)

Read across the three boxes and a clear pattern appears: the same core chapters are called on repeatedly. Each box names only the chapters that its own examples make most visible; in practice every area uses every chapter. Mechanics, for instance, uses complex numbers for oscillations, vector analysis for forces derived from a potential energy, and multiple integrals for centers of mass and moments of inertia, while electromagnetism uses series for multipole expansions, and matrices and ordinary differential equations for circuits. That is why these methods are best studied as an integrated toolkit rather than learned piecemeal. When a technique appears later in the notes and its purpose is not immediately obvious, return to this page and connect it to the physical question it was designed to answer.

Video lectures. The full lecture is below, and all lectures are in the course playlist.

Video Lecture 1: Why Mathematical Methods? (full lecture)

Preface

About These Notes

Mathematics is the language through which we learn to understand nature. By mastering this language, we become able to describe physical systems, construct models, make predictions, and, in many cases, guide or control their behavior. For this reason, mathematical methods are not only technical tools; they are an essential part of how physicists think about the physical world.

These lecture notes were developed for PHYS 3260: Mathematical Physics at Kennesaw State University. The purpose of the course is to introduce some of the most important mathematical methods used in physics, while keeping physical meaning at the center of the discussion. The goal is not simply to learn formulas, but to understand why a method is useful, when it should be applied, and what it tells us about a physical system. Although the course is intended primarily for physics students, many of these methods are also useful for students in engineering and other quantitative fields.

We begin with infinite series, power series, and Taylor expansions because approximation is one of the central ideas of physical modeling. Exact solutions are often unavailable, and series provide a systematic way to represent complicated functions in forms that are easier to analyze and use. The course then turns to complex numbers, which are indispensable in many areas of physics. In some subjects, such as quantum mechanics, they are part of the structure of the theory itself; in others, they provide a natural and elegant way to describe oscillations, waves, and exponential behavior, and they often simplify the solution of differential equations.

Linear algebra follows naturally, since many physical problems are expressed in terms of vectors, matrices, and linear transformations. A solid understanding of these ideas is essential for topics such as coupled systems, normal modes, and quantum mechanics. From there, the course moves to functions of several variables. Partial differentiation and multiple integration provide the tools needed to describe systems that depend on more than one variable, while coordinate transformations and Jacobians help us move between different mathematical descriptions of the same physical problem.

Vector analysis then builds the language of fields. Concepts such as gradient, divergence, and curl are central to electromagnetism, fluid flow, and many other parts of physics. The integral theorems of vector calculus show how local properties and global behavior are connected, giving mathematical structure to important physical laws.

The later chapters focus on methods for solving physical problems. Fourier series and Fourier transforms allow functions to be decomposed into simpler modes, an idea that is fundamental in wave motion, signal analysis, heat flow, and quantum theory. Ordinary differential equations describe how systems evolve and respond to external influences. Series solutions and special functions arise when these equations cannot be solved in elementary form, while partial differential equations bring together many of the main ideas of the course in the study of waves, potentials, diffusion, and boundary-value problems.

The organization and style of these notes are inspired by Mary L. Boas’s Mathematical Methods in the Physical Sciences. Like that text, these notes aim to be practical, clear, and closely connected to applications. Many examples are drawn from physics, and one of my future goals is to include more physical examples throughout the notes. I hope this text serves not only as a guide for this course, but also as a useful reference for later study. Mathematical methods become powerful through practice, patience, and repeated connection to real problems, and these notes are meant to support that process.

Erfan Saydanzad Department of Physics Kennesaw State University
